Engineering
Like great masterpieces, Classic Tool & Die’s design and build solutions are balanced creations of innovation and inspiration, backed by the skill and vision of an experienced manufacturer.
Dedicated engineers with years of experience in die design plan the development of your tools. Optimizing material usage, minimizing maintenance and eliminating customers’ concerns about running high-volume dies is our area of expertise.
Die simulation lets us test draw and form stations before they are manufactured, predicting formability problems before tooling takes place.
CAD and Software
- Cimatron — 3D die design and cutter path
- Dynaform — die simulation and analysis
- Fastform — die blanking simulation
- Geomagic — scan data and reverse engineering
- BobCAD — CAD/CAM
- PC-DMIS — CMM
Supported files
We can read most common CAD formats, including STEP, IGES, Parasolid (X_T), SAT/ACIS, DXF/DWG, STL, VDA and Cadkey/KeyCreator. Please email Engineering before sending data if you are unsure whether we can read your file format.
